Features:
HP:1HP-10HP
Pole:2P, 4P
Frame: 56-215T
Start Torque: Tst≥250%
Enclosure: ODP
IP Class: IP23
Service factor: 1.0,1.15
CSA&CUS,UL certified
Accept Manual Thermal Protector
1. Cixi Waylead Electric Motor Manufacturing Co.,Ltd is located in Cixi City, Zhejiang Province, China, close to the famous international ports Shanghai and Ningbo. The economic and technical conditions are superior, and the transportation is convenient.
2. Cixi Waylead is a professional Dripproof Single-Phase Air-Compressor Motor Suppliers and Dripproof Single-Phase Air-Compressor Motor company with rich industry experience. We can make "tailor-made" Dripproof Single-Phase Air-Compressor Motor according to the requirements of different customers. All our motors are exported to the United States, Canada, Mexico, Japan, Australia, New Zealand, Saudi Arabia, etc. Motors are widely used in woodworking, air compressors, blowers, fans, water pumps, hydraulic pumps, etc.
3. All our oem Dripproof Single-Phase Air-Compressor Motor and commercial processors have passed CSA & CUS certification, and some motors also have UL certification. The three-phase high-efficiency super-efficiency motor has passed the certification of Canada and the United States Department of Energy in 2007 and 2010.
4. On-site quality and production are managed by "6S". Implement ISO9001 international quality management system standards. Waylead has won the favor of many well-known international buyers with its excellent quality, reasonable price, punctual delivery and good service. Waylead looks forward to working with you in the near future!
|
HP |
RPM |
NEMA |
Model |
Volts |
HZ |
ENCL. |
S.F |
Full Load AMPS |
WGT. |
|
1 |
3600 |
56 |
D56 1S2C |
115/208-230 |
60 |
ODP |
1.15 |
12/6.4-5.8 |
30 |
|
1800 |
56 |
D56 1S4C |
115/208-230 |
60 |
ODP |
1.15 |
11.5/6.0-5.7 |
38 |
|
|
1800 |
143T |
D143T1S4C |
115/208-230 |
60 |
ODP |
1.15 |
11.5/6.0-5.7 |
41 |
|
|
1.5 |
3600 |
56 |
D56 1.5S2C |
115/208-230 |
60 |
ODP |
1.15 |
14.5/7.8-7.2 |
37 |
|
1800 |
56 |
D56 1.5S4C |
115/208-230 |
60 |
ODP |
1.15 |
15.5/8.1-7.6 |
42 |
|
|
1800 |
145T |
D145T1.5S4C |
115/208-230 |
60 |
ODP |
1.15 |
15.5/8.1-7.6 |
45 |
|
|
3600 |
145T |
D145T1.5S2C |
115/208-230 |
60 |
ODP |
1.15 |
14.5/8.0-7.6 |
41 |
|
|
2 |
3600 |
56 |
D56 2S2C |
115/208-230 |
60 |
ODP |
1.15 |
18/10.1-9.2 |
44 |
|
1800 |
56 |
D56 2S4C |
115/208-230 |
60 |
ODP |
1.15 |
19.0/10-9.3 |
47 |
|
|
1800 |
145T |
D145T2S4C |
115/208-230 |
60 |
ODP |
1.15 |
19.0/10-9.3 |
50 |
|
|
3600 |
145T |
D145T2S2C |
115/208-230 |
60 |
ODP |
1.15 |
18/10.2-9.4 |
48 |
|
|
3 |
3600 |
56 |
D56 3S2C |
115/208-230 |
60 |
ODP |
1.15 |
25/14.2-13 |
60 |
|
3600 |
145T |
D145T3S2C |
115/208-230 |
60 |
ODP |
1.15 |
25/14.2-13 |
67 |
|
|
1800 |
182T |
D182T3S4A |
208-230/460 |
60 |
ODP |
1.15 |
13.5-12/6.2 |
88 |
|
|
5 |
3600 |
184T |
D184T5S2A |
208-230/460 |
60 |
ODP |
1.15 |
22-20/10 |
95 |
|
1800 |
184T |
D184T5S4A |
208-230/460 |
60 |
ODP |
1.15 |
22.5-20/10 |
96 |
|
|
6 |
3600 |
56 |
D566S2A |
230 |
60 |
ODP |
1.0 |
22.8 |
56 |
|
7.5 |
1800 |
213T |
D213T7.5S4A |
208-230/460 |
60 |
ODP |
1.15 |
32.8-30/15.2 |
140 |
|
10 |
1800 |
215T |
D215T10S4A |
208-230/460 |
60 |
ODP |
1.0 |
41.2-39/19.5 |
153 |
The Dripproof Single-Phase Air-Compressor Motor is designed to deliver reliable performance in air-compressor applications, offering a robust solution within the single-phase motor category. Compared to standard single-phase motors, this model emphasizes enhanced protection against external liquid ingress, ensuring operation in environments where minor exposure to moisture may occur. It is available in power ranges from 1HP to 10HP, accommodating a variety of air-compressor sizes, and provides options for 2-pole and 4-pole configurations to meet different speed requirements. The motor features an Open Drip Proof (ODP) enclosure, IP23 protection class, and a service factor of 1.0 or 1.15, allowing continuous and stable operation. Certification from CSA, CUS, and UL ensures compliance with international safety standards, while the acceptance of manual thermal protectors adds an extra layer of operational safety.
Structure and Protection:
The motor’s dripproof design reduces the risk of liquid damage while maintaining adequate ventilation. Its IP23 protection class ensures that splashing water or condensation will not compromise the motor’s internal components, extending service life in demanding conditions.
Performance Parameters:
With horsepower options ranging from 1HP to 10HP and 2-pole or 4-pole configurations, the motor can be tailored for various air-compressor applications, providing flexibility in speed and torque requirements. The start torque (Tst ≥ 250%) allows efficient startup even under heavy load conditions.
Authentication and Security:
CSA, CUS, and UL certifications verify the motor’s compliance with international safety and performance standards. Additionally, it supports manual thermal protectors, enabling protection against overheating and improving operational reliability.
Application Scope:
This motor is primarily used in air compressors across industrial, commercial, and light manufacturing sectors. Its combination of durability, protection, and customizable performance parameters makes it suitable for continuous operation in environments with occasional exposure to moisture or dust.
Installation and Maintenance:
Available in frame sizes 56-215T, it is compatible with standard mounting configurations. The ODP enclosure simplifies maintenance, providing easy access for inspections or component replacements.
